Skywire LTE CAT 1, WorldWide, GNSS

SKU: NL-SW-LTE-TC1WWG Categories: Embedded Modems, Tag:

Skywire® Global CAT 1 Embedded Modem


NimbeLink, a global leader in embedded cellular modem technology and asset tracking solutions, has introduced the Skywire® 4G LTE CAT 1 WW modem. This Skywire modem leverages Category 1 technology. The NL-SW-LTE-TC1WWG is ideal for delivering fast reliable cellular connectivity to products with applications World Wide. The modem supports GNSS, dual SIMs, a single SKU for both AT&T / Verizon networks, integrated TCP/IP stacks, plus is AT&T’s FirstNet (Band 14) capable.Skywire embedded modems dramatically reduce the cost, risks and timelines of IoT product development. With known-good RF engineering and fully validated software, Skywire allows you to focus on your application and not engineering cellular radios. Standardized connectivity gives you flexibility to update and alternate radios for new geographies, carriers and technologies. Further, our embedded modems are “End-Device Certified”, meaning your end-product will not need to go through the complex process of carrier certification. This is critical for the first release of your product and each iteration as you obtain market feedback. Skywire modems significantly reduce time-to-market and are ideal for product development through large-scale production. All Skywire modems are patented and backed by industry leading documentation and expert-level product support.

Skywire FAQs
Skywire Modems Comparison Chart

Product Brief Buy Now

  • Small Skywire Form-Factor
  • 4G LTE Category 1 with 3G fallback*
  • U.FL Antenna ports for easy antenna integration
  • Band 14 support – FirstNet on AT&T’s network
  • Dual SIM support with integrated solder down SIM and external 3FF SIM card slot
  • GNSS support for GPS, Glonass, Beidou, Galileo, and QZSS
  • Multi-carrier support on a single device
  • Skywire family pin compatibility
  • RoHS compliant
  • Development kits available
  • Longest Network Life
  • CAT 1 LTE Speeds (Up to 10 Mbps down/ 5 Mbps up)
  • Global LTE coverage with 3G fallback
  • Improved reception with RX diversity
  • 8 Band LTE support
  • Integrated GNSS support
  • Easy to integrate – pin compatible with all Skywire modems
  • Bundled Data Plan Available
  • Throughput: Download: LTE: 150 Mbps | HSPA+: 42.0 Mbps | Upload: LTE: 50 Mbps | HSPA+: 5.76 Mbps
  • Active Cell: TBDmA
  • Average: TBDmA
  • Peak: TBDmA
  • Idle: TBDmA
  • Sleep: TBDmA
  • Input Voltage: 3.4V-4.2V
  • I/O Voltage: 1.8V-5.5V
  • Temperature Range: -40º to 85ºC
  • Dimensions: 29.9mm x 34.4mm x 10.5mm
  • RoHS compliant

Deployable Region



Buy Now


Skywire LTE CAT 1, World Wide, GNSS

Buy Now


Skywire development kit version 2 includes baseboard, antenna, power supply, AT&T SIM card, and debug cables. (Does not include Skywire modem.)

Buy From


SIM card, Tri-cut, 2/3/4FF, Verizon, LTE CAT-M1, Commercial Temp range

Buy From


SIM card, Tri-cut, 2/3/4FF, AT&T, 4G LTE, Commercial Temp range

Buy From

Need Help Choosing?

If you need help selecting a Development Kit, or if you have any other questions, please do not hesitate to contact us.
