Skywire® 4G LTE CAT 4 North America Embedded Modem

SKU: NL-SW-LTE-TC4NAG

The Skywire® 4G LTE CAT 4 NA embedded modem leverages Category 4 technology. This embedded modem is ideal for delivering fast, reliable cellular connectivity for products in North America. The modem supports GNSS, dual SIMs, a single SKU for North American carrier networks and onboard network stacks. This embedded modem is also capable of running on FirstNet and includes support for Band 14.

The NL-SW-LTE-TC4NAG is pin compatible with previous modems and is designed to replace the NimbeLink CAT 3 Skywires NL-SW-LTE-TNAG-X and NL-SW-LTE-TSVG-X, with higher performance at a lower cost.

Skywire embedded modems dramatically reduce the cost, risks and timelines of IoT product development. With known-good RF engineering and fully validated software, Skywire allows you to focus on your application and not engineering cellular radios. Standardized connectivity gives you flexibility to update and alternate radios for new geographies, carriers and technologies. Further, our embedded modems are “End-Device Certified”, meaning your end-product will not need to go through the complex process of carrier certification. This is critical for the first release of your product and each iteration as you obtain market feedback. Skywire modems significantly reduce time-to-market and are ideal for product development through large-scale production. All Skywire modems are patented and backed by industry leading documentation and expert-level product support.

Product Brief Buy Now
SKU: NL-SW-LTE-TC4NAG Categories: Embedded Modems, Tag:

Skywire® 4G LTE CAT 4 North America Embedded Modem

SKU: NL-SW-LTE-TC4NAG

The Skywire® 4G LTE CAT 4 NA embedded modem leverages Category 4 technology. This high speed embedded modem is ideal for delivering fast, reliable cellular connectivity for products in North America. The modem supports GNSS, dual SIMs, a single SKU for North American carrier networks and onboard network stacks. This embedded modem is also capable of running on FirstNet and includes support for Band 14.

The NL-SW-LTE-TC4NAG is pin compatible with previous modems and is designed to replace the NimbeLink CAT 3 Skywires NL-SW-LTE-TNAG-X and NL-SW-LTE-TSVG-X, for higher performance wireless networks at a lower cost.

Skywire embedded modems dramatically reduce the cost, risks and timelines of IoT product development. With known-good RF engineering and fully validated software, Skywire allows you to focus on your application and not engineering cellular radios. Standardized connectivity gives you flexibility to update and alternate radios for new geographies, carriers and technologies. Further, our embedded modems are “End-Device Certified”, meaning your end-product will not need to go through the complex process of carrier certification. This is critical for the first release of your product and each iteration as you obtain market feedback. Skywire modems significantly reduce time-to-market and are ideal for product development through large-scale production. All Skywire modems are patented and backed by industry leading documentation and expert-level product support.

Skywire FAQs

Skywire Modems Comparison Chart

Product Brief

Buy Now

  • Skywire Form-Factor
  • 4G LTE Category 4 with 3G fallback
  • All RF Engineering contained within the modem
  • Carrier End-Device certified
  • U.FL port for flexible antenna options
  • Band 14 support – FirstNet compatible
  • Dual SIM support with integrated solder down SIM and external 3FF SIM card slot
  • Direct module access via Serial UART or USB
  • GNSS support for GPS, Glonass, Beidou, Galileo, and QZSS
  • Multi-Carrier Support on a Single Device
  • Skywire family pin compatibility
  • RoHS compliant
  • Development kits available
  • Longest Network Life
  • CAT 4 LTE Speeds (Up to 150 Mb down/50 Mb up)
  • Easily connect to Verizon, AT&T, or T-Mobile networks.
  • Improved reception with RX diversity
  • 8 Band LTE support
  • Integrated GNSS support
  • Bundled data plans available
  • Throughput: 10 Mbps Download/5 Mbps Upload
  • Average: N/A
  • Peak: N/A
  • Idle: N/A
  • Sleep: N/A
  • Supply Voltage: 3.4V – 4.2V (3.8V Nominal)
  • I/O Voltage: 1.65V-5.5V
  • Temperature Range: -40ºC to +85ºC
  • Dimensions: 29mm x 33mm x 10.5mm
  • Weight: 8 grams
  • RoHS Compliant

Deployable Region

Compatible Carriers

Bands

Buy Now

NL-SW-LTE-TC4NAG

Skywire LTE CAT 4, North America, GNSS, Firmware M0F.660006

NL-SW-LTE-TC4NAG-B

Skywire LTE CAT 4, North America, GNSS, Firmware M0F.660012

NL-SWDK2

Skywire development kit version 2 includes baseboard, antenna, power supply, AT&T SIM card, and debug cables. (Does not include Skywire modem.)

Buy From

NL-SIM-COM

3FF Commercial Temp range SIM card, Verizon

NL-SIM-IND

3FF Industrial Temp range SIM card, Verizon

NL-SIM-ATT-CTRI

SIM card, Tri-cut, 2/3/4FF, AT&T, 4G LTE, Commercial Temp range

NL-SIM-VER-TRI

3FF Commercial Temp range SIM card (2FF, 3FF, 4FF), Verizon
